Spare Parts & Options
For additional information on spare parts, Contact Acorn™ or download our Spare Parts PDF.
For additional information on spare parts, Contact Acorn™ or download our Spare Parts PDF.
Click on the links below to scroll down the page:
• Brake Options
• Swivel Lock / Toe Guard
• Replacement Bearings
• Washers / Seals
• Spanner Bushings
• Axle Kits
• ISO Top Plates
• Top Plates & OAH's
• Replacement Parts
 |
Wheel Cam Brake (WCB) Designed for use with Roller, Delrin and Oilex bearing wheel casters. Spare Parts & Options PDF |
 |
Single Side Brake (SSB) Right hand installation standard, left hand option availble. Spare Parts & Options PDF |
 |
Double Side Brake (DSB) Pedal on both sides for easy access. Spare Parts & Options PDF |
 |
Total Lock Brake (TLB) Corrosion resistant brake features rugged thermoplastic construction. Locks both wheel and swivel. Spare Parts & Options PDF |
 |
Grip Lock Brake (BLB) Corrosion resistant brake features rugged thermoplastic construction. (Does not work with swivel lock.) Spare Parts & Options PDF |
 |
Face Brake (FBA) Step down to engage and release. Spare Parts & Options PDF |
 |
Face Brake (FBB) Step down to engage and release. Spare Parts & Options PDF |
 |
Face Brake (FBC) Step down to engage and release. Spare Parts & Options PDF |
 |
Face Brake (FBD) Step down to engage and release. Stainless steel. Spare Parts & Options PDF |
 |
Poly Cam Brake (PCB) Positive locking action wheel tread. Spare Parts & Options PDF |
 |
Wrap Around Brake (WAB) Foot operated on both sides. Use with straight roller bearing. Overall height must be greater than 5-1/4". Spare Parts & Options PDF |
 |
Face Contact Brake (FCB) Positive locking action wheel tread. Spare Parts & Options PDF |
 |
Swivel Lock (Bolt On) Spring activated plunger can be disengaged for continuous swiveling or engaged for straight line travel. Available on all models Spare Parts & Options PDF |
 |
Notched Yoke Base Option Notches in 90º intervals are required for swivel locks. The notch allows the spring activated plunger to lock the swivel. Spare Parts & Options PDF |
 |
Toe Guard (Swivel Caster) Spare Parts & Options PDF |
 |
Toe Guard (Rigid Caster) Spare Parts & Options PDF |
 |
Roller Bearings Roller bearings offer the best compromise between capacity, rollability and value in a bearing. Constructed with a series of hardened steel rollers encased in a split metal sleeve cover. Spare Parts & Options PDF |
 |
Heavy Duty Roller Bearings An improved version of the standard roller bearing featuring a solid outer sleeve for simplified installation and improved greese retension. Spare Parts & Options PDF |
 |
Stainless Steel Roller Bearings A fully stainless steel version of the standard roller bearing. Provides higher capacity and improved rollability over Derlin bearings. Spare Parts & Options PDF |
 |
One Piece Derlin Bearings A one-piece insert bearing constructed from Derlin material. A standard bearing for use with stainless steel casters where a cam style brake is used. Spare Parts & Options PDF |
 |
Flanged Roller Bearings Flanged roller bearings are a higher capacity alternative to flanged ball bearings. Spare Parts & Options PDF |
 |
Flanged Brass Bearings Flanged brass bearings are ideal for high-heat or corrosive environments or for wet applications where Derlin bearings are inappropriate. Spare Parts & Options PDF |
 |
Flanged Derlin Bearings Derlin is a high-strength, wear resistant material with a low coefficient of friction. This, combined with a good chemical resistance and low moisture absorption make it ideal for use as a wheel bearing. One-piece Derlin bearings are required when a cam style brake is used. Spare Parts & Options PDF |
 |
Flanged Ball Bearings Flanged ball bearings provide improved rollability over standard roller bearings. However, load capacity is reduced. Spare Parts & Options PDF |
 |
Presision Ball Bearings Fully sealed precision ball bearings (available in standard and stainless steel) provide greatly increased rollability and higher capacity over roller bearings. Ideal for towline applications. Spare Parts & Options PDF |
 |
Precision Top Hat Spacers Precision machined Top Hat spacers are designed for use with precision ball bearings. Spare Parts & Options PDF |
 |
Retainer Washers Vulca Seals Head Seals |
 |
Steel Spanner Bushing Spanner bushings are used to "span" the distance between the legs for the fork. The spanner is locked in place, allowing the bearing to turn freely. Precision-machined and cross-drilled to allow for lubrication of the wheel bearing. Spare Parts & Options PDF |
 |
Stainless Steel Spanner Bushing Also available: |
 |
Greese Axles Greese axles are hollow axles that are fitted with a greese nipple to hollow periodic lubrication of the wheel bearing. Spare Parts & Options PDF |
 |
Plain Axles Plain axles (without greese fittings) are used with spanners and bearings that do not require lubrication. Spare Parts & Options PDF |
 |
Stainless Steel Axles A fully stainless version of the standard greese axle. Spare Parts & Options PDF |
Click to enlarge |
Click to enlarge |
Click to enlarge |
Additional ISO Top Plate sizes and bolt hole centers are available with Kingpinless style casters.
| Top Plates & OAH's We regularly carry top plates with other than standard bolt hole centers. These will interchange with standard top plates. There are other optional top plates and/or bolt hole centers available. Click on the PDF below for details. Top Plate & OAH PDF |
| Replacement Parts Click on the PDF below to view part numbers of caster axles, spanner bushings, straight roller bearings and washers for most standard casters. Replacement Parts PDF |
